Tantalum Wire for Electrical Light Source

2022-05-12 来源:原创 浏览量:1784

分享到：

产品用途：

用于电光源行业、3D打印制粉、制作加热网、喷涂材料、医疗等领域。

Application:

They are used for making powder by 3D printing, making heating nets, spraying materials, and in the electric light source, medical and other fields.

产品性能参数/Product Property Parameters：

化学成分Chemical Compositions (%，不大于/max)
牌号Grade	O	C	Si	N	Fe	H	Nb	Ni	W	Mo	Ti	Cr	Ta
DTa1	0.02	0.005	0.003	0.0035	0.0045	0.0015	0.005	0.0025	0.002	0.002	0.005	0.0025	99.95
DTa2	0.02	0.005	0.02	0.0035	0.0045	0.0015	0.005	0.0025	0.002	0.002	0.005	0.0025	99.95

直径及公差Diameter and Tolerance (mm)：

直径Diameter

0.13-0.20

0.21-0.60

0.60-2.0

公差Tolerance

±0.005

±0.006

±0.01

注：用户如有具体要求，双方具体商。

Note: Special requirements will be agreed upon by the supplier and buyer.
